TROUBLESHOOTING
1.2 ERROR MESSAGES
1 - 5
1
Search
Book TOC
Go Back
Alarm 4 (
g
) Time-out in an attempt to drive the Ventin
g
/Samplin
g
needle’s axis
mechanism to/from its ori
g
in.
IP - 13
Alarm 4 (h) Time-out in an attempt to drive the Mixin
g
Z2-axis mechanism
to/from its ori
g
in.
IP - 14
Alarm 4 (i) Time-out in an attempt to drive the X-axis mechanism to its
Slowdown Sensor.
IP - 15
Alarm 4 (j) X Limit Sensor Time-out in an attempt to drive the X-axis
mechanism to/from its limit sensor.
IP - 11
Alarm 4 (k) Z1 Limit Sensor Time-out in an attempt to drive the
Ventin
g
/Samplin
g
needle’s axis mechanism to/from its ori
g
in.
IP - 13
Alarm 4 (l) Time-out in an attempt to drive the Mixin
g
Paddle’s axis
mechanism to its Position Sensor.
IP - 16
Alarm 4 (m) Rack-B Sensor did not detect a Rack. IP - 17
Alarm 4 (n) At least 2 Rack Sensors A throu
g
h D not in correct state durin
g
phases of rack rotation.
IP - 17
Alarm 4 (o) Rack Sensor A not in correct state durin
g
rotation phase. IP - 17
Alarm 4 (p) Rack Sensor B not in correct state durin
g
rotation phase. IP - 17
Alarm 4 (q) Rack Sensor C not in correct state durin
g
rotation phase. IP - 17
Alarm 4 (r) Rack Sensor D not in correct state durin
g
rotation phase. IP - 17
Table 1 - 1 Error Messages(continued)
