CELL-DYN
®
3/35 Sample Loader TS Guide 9140234B-June 1997
VERIFICATION PROCEDURES
VP - 1 Power Supply Check [NON-CE MARK]
3 - 10
3
Search
Book TOC
Go Back
4. Verify the followin
g
:
LED on +24V Power Supply
ON
.
LED on +5V Power Supply
ON
(
E and G Loaders
- View from Front;
F Loader
- View from
Rear).
LED on Blood In-Line Sensor
ON
if no blood in Sample Line.
F Loader LED
ON
(located on Barcode Power Supply).
-DS3 LED
ON
(located on Barcode Decoder Board).
5. Verify volta
g
e at CPU Main Board, U8 Pin 3 = +15±0.8V.
6. Verify volta
g
e at ±12V Power Supply equals 12V±0.4 (Fi
g
ure 3-1, Pa
g
e-3-11 or , Pa
g
e-3-12).
