CELL-DYN
®
3/35 Sample Loader TS Guide 9140234B-June 1997
VERIFICATION PROCEDURES
VP - 3.16 X-Axis Solenoid to Rack Guide Check
3 - 56
3
Search
Book TOC
Go Back
6.
• IF Check is OK, Platen Procedure is Complete.
• IF Check Fails,
g
o to “VP - 3.17 X-Axis Solenoid to Rack Guide Adjustment” (Pa
g
e 3-57).
Figure 3-25 Solenoid to Rack Guide
--- END ---
Strai
g
ht
Ed
g
e
SL-172B
Rack
Guide
X-Axis
Solenoids
Ensure Neither
Solenoid Extends
Past Rack Guide at
Ri
g
ht and Left Stops
