CELL-DYN
®
3/35 Sample Loader TS Guide 9140234B-June 1997
VERIFICATION PROCEDURES
VP - 10.2 Tube Positioning Arm Alignment
3 - 137
3
Search
Book TOC
Go Back
6. Ensure tube positionin
arm(s) does not dra
on top of platen. If necessary, loosen solenoid
bracket screws and adjust.
Only [OLD] F Loader with Clamp - (Others not Adjustable)
a. To raise arms sli
htly, loosen screws on solenoid bracket (Fi
ure 3-74).
b. Push bracket up to
ive clearance.
