CELL-DYN
®
3/35 Sample Loader TS Guide 9140234B-June 1997
VERIFICATION PROCEDURES
VP - 11.1 Barcode Check
3 - 143
3
Search
Book TOC
Go Back
Figure 3-77 Barcode Alignment Tube Position
4. Put Sample Loader in Manual Mode.
a. Press and Hold
MAN
and
START
.
b. Cycle Power
Off/On
while holdin
g
keys down until BEEPING stops.
5. Set
BAR (1/0) Switch
to
1
.
Tool in front of
Barcode Reader
Needle
Ali
g
nment
Tool in Tube
Position #1
SL-101C
