6241A/6242 DC Voltage Current Source/Monitor Operation Manual
5.2.5 Measurement Function
5-29
5.2.5.2 Measurement Ranging
Measurement range is determined by the relationship between measurement auto range ON/OFF and the
Source/Measurement function.
NOTE: For Pulse source and Pulse-sweep source mode, the range is always fixed even when the measurement
auto range is set to ON.
1. Operating Range for Measurement Auto Range
When the measurement auto range is enabled, the upper and lower range levels are within ±20 digits
of the values shown in the table below.
• 6241A
Source function
Measurement auto range OFF Measurement auto range ON
Voltage-measurement Current-measurement
Voltage-measurement Current-measurement
Voltage-source Fixed to source range Fixed to limiter range Fixed to source range
Current-source Fixed to limiter range Fixed to source range Fixed to source range
: Auto range operation enabled (operates with the limiter range as the maximum)
Measurement function Range
Auto range level
DOWN UP
Voltage-measurement 300 mV - 321.000
3 V 0.29999 3.21000
30 V 02.9999 -
Current-measurement 30 μA-32.1000
300 μA 029.999 321.000
3 mA 0.29999 3.21000
30 mA 02.9999 32.1000
300 mA 029.999 321.000
500 mA 299.999 -
