6241A/6242 DC Voltage Current Source/Monitor Operation Manual
9.4 General Specification
9-19
9.4 General Specification
Operating environment conditions: Ambient temperature 0ºC to +50ºC, relative humidity 85% RH or
below, with no condensation
Storage environment conditions: Ambient temperature -25ºC to +70ºC, relative humidity 85% RH or
below, with no condensation
Warming up time: 60 minutes or longer (Until it settles in the specified accuracy.)
Display: 16 segment × 12 digits
Fluorescent character display tube
Power supply: AC power 100 V, 120 V, 220 V, and 240 V (User selectable)
Line frequency: 50 Hz/60 Hz
Power consumption: 6241A: 95 VA or less
6242: 180 VA or less
External dimensions: Approx. 212 (width) × 88 (height) × 400 (depth) mm
Mass: 6241A: 6 kg or less
6242: 6.5 kg or less
Safety: Compliant with IEC61010-1
EMI: EN61326 classA
Option No. Standard OPT.32 OPT.42 OPT.44
Power voltage 100 V 120 V 220 V 240 V
Specify the option number when ordering.
When changing the power voltage, use only a power cable and rated
fuse approved for the respective country.
