6241A/6242 DC Voltage Current Source/Monitor Operation Manual
9.3 Set Time
9-17
Voltage-measurement input resistance: 1 GΩ or more
Voltage-measurement-input leakage current:
±1 nA or below
GPIB interface: Compliant with IEEE-488.2-1987
Interface function;
SH1, AH1, T5, L4, SR1, RL1, PP0, DC1, DT1, C0, E2
Connector; Amphenol 24 pin
USB interface: USB 2.0 Full-speed
Connector; Type B
External control signal: TRIGGER IN
INTERLOCK, OPERATE IN/OUT
COMPLETE OUT, SYNC OUT
Connector; BNC
9.3 Set Time
Minimum pulse width: 50 μs
Minimum step (repeat) time: Source/measurement range; Fixed, Integration time; 100 μs, measure-
ment/source delay time; Minimum, Calculation; OFF, and in Voltage
and current-measurement
Source delay time:
Measurement Memory mode Minimum step time
OFF - 0.5 ms
BURST 2 ms
ON NORMAL
10 ms
OFF
Set range
Setting
resolution
*7
Accuracy
0.030 ms to 60.000 ms 1 μs
60.01 ms to 600.00 ms 10 μs ±(0.1% + 10 μs)
600.1 ms to 6000.0 ms 100 μs
6001 ms to 59998 ms 1 ms
