6241A/6242 DC Voltage Current Source/Monitor Operation Manual
2.2.3 Menu Operation
2-25
2.2.3 Menu Operation
The 6241A/6242 functions and parameters are set on hierarchical menus.
The menus have a 3-level hierarchy.
Level 1 Category level Select menus and categories.
Level 2 Select level Select a parameter to set within the category.
Level 3 Input/Run level Input or select the set value.
Figure 2-14 shows an overview of the menu operations.
2.2.3.1 Method of Menu Operation
The menu operation procedure is shown below.
1. Press MENU.
The selection screen for the Category level A) SOURCE to M) SYSTEM
appears.
2. Select categories by using , or .
3. Press to enter the Select level.
4. Select parameters by using , or .
5. Press to enter the Input/Run level.
6. Parameter setting and execution operations differ according to the parameter
type. Set the parameters by rotating
, and move the cursor position by using or .
Table 2-1 shows the menu and key operations.
NOTE: During sweeps, the MENU key is unavailable.
