6241A/6242 DC Voltage Current Source/Monitor Operation Manual
4.2.10 OPR/SUSPEND (Operating/Suspend)
4-16
4.2.10 OPR/SUSPEND (Operating/Suspend)
OPR key: Switches between Operate and Suspend.
Operate: Turns the output status ON and the OPR indicator turns on.
Displays measurement value when the measurement is ON. When
it is OFF, the display turns off. The following items are displayed
depending on the source mode.
DC: Generates a setting value and displays the measurement
value.
PLS: Generates pulse and displays the measurement value.
DC-SWP and PLS-SWP:
Generates bias value and waits for measurement.
Generates Sweep data and waits for trigger input. The
trigger input starts the Sweep and displays the
measurement value.
Suspend: Outputs Suspend voltage without turning OFF the output relay.
OPR indicator blinks. It displays Suspend voltage and displays
Suspended status at the header.
In HZ: High impedance status
In LZ: Low impedance status
SUSPEND key (SHIFT):
Sets Suspend in Standby or Operating status.
NOTE: Sweep data is generated when the status is switched at DC-SWP and PLS-SWP as follows:
• From Standby to Operate
• From Standby to Suspend
• Switches to Operate if the sweep parameter is changed during Suspend.
4.2.11 SHIFT/LOCAL (Shift Mode/Local)
SHIFT key (In Normal Operation): Functions as SHIFT key, and the SHIFT indicator turns on.
At Shift status, function names printed in blue characters on the
panel are enabled. Press the SHIFT key again to release the shift
mode.
LOCAL key (In Remote Operation): Releases remote operation.
Turns off RMT indicator and switches from remote control to
Panel operation.
NOTE: Local operations are prohibited if the LLO (Local Lock Out) command is set on the GPIB/USB Inter-
face.
