6241A/6242 DC Voltage Current Source/Monitor Operation Manual
5.2.8 Source Timing and Measurement Timing
5-41
5.2.8 Source Timing and Measurement Timing
The 6241A/6242’s timing of source and measurement differs depending on the source mode as shown in
Table 5-11.
To ensure accurate measurement, consider the relevant timings for source and measurement, and set the
relevant parameters.
Table 5-11 Source Mode and Time Parameters to be Considered
Source mode Th Tds Td Tw Tp Tm Timing diagram
DC
Trigger mode
AUTO
Table 5-2
Trigger mode
HOLD
Pulse Table 5-3
DC Sweep Table 5-5
Pulse Sweep Table 5-6
Item Description Category level
Select level
Input/Run level
Th Hold time MENU key
↓
D) TIME
1) Hold Time
Tds Source delay time 2) Src Delay
Td Measurement delay time 3) Meas Delay
Tw Pulse width 4) Pls Width
Tp Period time 5) Period
Tm Measurement time (Integration time +
Processing time)
MENU key
↓
E) MEASURE
2) Integ Time
