6241A/6242 DC Voltage Current Source/Monitor Operation Manual
4.2.7 MODE Key (Source Mode)
4-15
4.2.7 MODE Key (Source Mode)
This key sets the source mode. Use , or to select the mode.
Source Mode Switches between source modes.
Enabled only when in Standby or Suspend.
DC: Sets the DC source mode, which generates DC
voltages/DC currents. DC indicator turns on.
PLS: Sets the pulse source mode, which generates pulse
voltages/pulse currents. PLS indicator turns on.
DC-SWP :
Sets the DC sweep source mode, which generates DC
voltage /current Sweep-waveforms.
DC and SWP indicators turn on.
PLS-SWP :
Sets the pulse sweep source mode, which generates
pulse voltage/current Sweep-waveforms. PLS and SWP
indicators turn on.
4.2.8 MON Key (Measurement Mode)
This key sets the measurement mode.
Monitor Switches measurement functions.
IM: Sets current-measurement function.
Displays “I” at the header and the measurement unit is
A.
VM: Sets voltage-measurement function.
Displays “V” at the header and the measurement unit is
V.
RM: Sets resistance measurement function.
Displays “R” at the header and the measurement unit is
Ω.
4.2.9 NULL/SEL key
NULL key: Sets the NULL calculation ON or OFF.
For more information on the NULL calculation function, refer to
Section 5.2.9.1, “NULL Calculation.”
SEL key: This key selects parameters on the Input level menu.
For more information, refer to Section 2.2.3, “Menu Operation.”
