ADCMT 6241A User Manual

6241A/6242 DC Voltage Current Source/Monitor Operation Manual
5.2.3 Sweep Source Mode Operation
5-12
5.2.3 Sweep Source Mode Operation
Table 5-4 below shows sweep source mode operation.
Table 5-4 Sweep Source Mode Operation (1/2)
Sweep types Operation Waveform
DC Sweep
Linear Sweep
Sweeps with step value staircase
wave between the designated start
value and stop value.
Fixed Sweep
Sweeps specified times of sample
counts with specified constant
value.
Random Sweep
Sweeps the stored source value
from the specified starting address
to the stop address.
Two-slope
Linear Sweep
Initially, sweeps the Step 1 value
staircase waveform between the
designated first value and middle
value. Then, sweeps the Step 2
value staircase waveform between
the designated middle value and
last value.
