6241A/6242 DC Voltage Current Source/Monitor Operation Manual
2.3 Saving and Loading Parameters
2-48
2.3 Saving and Loading Parameters
The 6241A/6242 can save the setting parameters in the non-volatile memory, Area 0 to 3.
The 6241A/6242 has a random memory data save area, separated from the parameter save area.
2.3.1 Auto Load at Power On
When the 6241A/6242 is turned on, it starts up with the setting parameters from when it was previously
turned off.
To start up using predefined parameters, parameters saved in Area 0 can be loaded at startup.
To select the parameter loading method at power on, select K) PARAMETER → 3) PON. Load on the
Menu screen.
P.OFF Start up using the parameters when the unit was last turned off.
Load0 Start up using the parameters saved in Area 0.
NOTE:
1. The auto load function does not apply to random memory. At power ON, the random memory saved in the
non-volatile memory is loaded.
2. The GPIB address, USB.Id and power on loading conditions are always saved in a different area and loaded
when the power is switched on.
2.3.2 Saving Parameters
Operation Character display area
1.
Press MENU and press or to select K)
PARAMETER.
K) PARAMETER
2.
Press to go to the Select level.
1) Parm Load
Load0
3.
Press or to select 2) Parm Save.
2) Parm Save
Save0
4.
Press to go to the Input/Run level.
2) Parm Save
Ent Save0
5.
Rotate to select the save area.
2) Parm Save
Ent Save2
6. Press ENTER.
7. When saving is complete, “Done” is displayed and
the menu reverts to the Select level.
2) Parm Save
Done
8. Press EXIT to exit the menu. 2) Parm Save
Save2
To Next Page
