6241A/6242 DC Voltage Current Source/Monitor Operation Manual
A-3
A.2 Error Message List
If an error occurs when using the 6241A/6242, an error number accompanied by an error message appear on
the screen. These are explained in the following:
Table A-2 Error Message List (1/4)
Classification
Display
error code
Message Explanation 6241A 6242
Self-test 001 ROM Chk SUM ROM check SUM error
002 Panel Comm Display communication/RAM error
Consecutive buzzer ON LCA data error
004 RAM Rd/Wt RAM read or write error
005 Analog Comm Analog communication error
008 Flash Write Flash memory write error
012 CAL data SUM CAL data SUM error
013 Param SUM Parameter SUM error
101 AD Ratio 1-2 Ratio test error between AD operation IR1 and IR2
102 AD Ratio 2-3 Ratio test error between AD operation IR2 and IR3
103 AD Ratio 3-4 Ratio test error between AD operation IR3 and IR4
104 AD Ratio 4-5 Ratio test error between AD operation IR4 and IR5
111 ADRST Sig Test error in analog unit RST line
112 ADRST Sig Test error in analog unit TRIG line
151 ADx10 Zero AD operation X10 ZERO test error
152 ADx1 Zero AD operation X1 ZERO test error
201 VSVM 0.3V Z VSVM 300 mV ZERO test error
202 VSVM 0.3V +F VSVM 300 mV +FS test error
203 VSVM 0.3V -F VSVM 300 mV -FS test error
204 VSVM 3V Zero VSVM 3 V ZERO test error
205 VSVM 3V +FS VSVM 3 V +FS test error
206 VSVM 3V -FS VSVM 3 V -FS test error
207
VSVM 30V Z VSVM 30 V ZERO test error -
VSVM 6V Zero VSVM 6 V ZERO test error -
208
VSVM 30V +FS VSVM 30 V +FS test error -
VSVM 6V +FS VSVM 6 V +FS test error -
209
VSVM 30V -FS VSVM 30 V -FS test error -
VSVM 6V -FS VSVM 6 V -FS test error -
