ADCMT 6241A User Manual

6241A/6242 DC Voltage Current Source/Monitor Operation Manual
5.2.3 Sweep Source Mode Operation
5-17
5.2.3.2 Pulse Sweep Source Mode Operation
Table 5-6 below shows the pulse sweep source mode operation.
For more information on the operation, refer to Section 5.2.3.1, “DC Sweep Source Mode Operation.”
Table 5-6 Pulse Sweep Source Mode Operation
Operational
Condition
Trigger
Mode
Explanation Operation Remarks
Operate ON
AUTO
Executes consec-
utive measure-
ments with the set
period time Tp.
Th: Hold Time
Tp: Period Time
Td: Measurement
Delay Time
Tds:Source Delay Time
Tm: Measurement Time
(Integration time +
Measurement data
processing time)
Tcn: Operation Processing Time
Trc: Range Change Processing
Time
HOLD
Executes mea-
surement after
trigger input.
Change the
source range
AUTO
Source range
changed while
sweeping.
HOLD
Tp
Th
Tp
Tm
Tds
Tw
Td Td
Tm
Tw
Tds
1
2
Bias value
Base value
Operate
Start trigger
COMPLETE OUT [HI/GO/LO]
TRIGGER IN
COMPLETE OUT [END]
COMPLETE OUT [FRONT]
SYNC OUT
Operate
Tp
Tp
Tds
Tw
Td
Tm Tm
Td
Tw
Tds
1
2
Start trigger
Base value
Bias value
Trigger
TRIGGER IN
COMPLETE OUT [HI/GO/LO]
COMPLETE OUT [END]
COMPLETE OUT [FRONT]
SYNC OUT
Th
Operate
Start trigger
Base value
Bias value
Source range changed
Operate
Start trigger
Base value
Bias value
Trigger
