6241A/6242 DC Voltage Current Source/Monitor Operation Manual
5.2.15 Self Test
5-66
5.2.15 Self Test
The 6241A/6242 can self-test the internal operation by turning on the power, executing the remote com-
mand, or manual operation.
1. For more information on the self-test items and output results, see Table 5-17.
Table 5-17 Self-test Items (1/2)
Display Error
Code
Description
Executing Method
Message
TER register (*1)
6241A 6242
Power ON *TST?
Key
operation
Register Data
1 001 ROM check SUM ROM Chk SUM
----
2 002 Display section ROM/RAM Panel Memory
3 003 LCA data LCA data
4 004 Reading from or writing into RAM RAM Rd/Wt
5 005 Display communication Panel Comm
6 011 Analog section communication Analog Comm
7 012 CAL data SUM CAL data SUM
a
2
8 013 Parameter SUM Param SUM 4
9 501 Calibration data lost CAL dt Lost 16
10 502 Save data lost Save dt Lost 32
11 503 Saved parameter data lost Para dt Lost 64
12 130 SCI communication error No resp SCI 128
13 101 Ratio between AD operation IR1 and IR2 AD Ratio 1 to 2
b
1
14 102 Ratio between AD operation IR2 and IR3 AD Ratio 2 to 3 2
15 103 Ratio between AD operation IR3 and IR4 AD Ratio 3 to 4 4
16 104 Ratio between AD operation IR4 and IR5 AD Ratio 4 to 5 8
17 111 Analog section RST line test ADRST Sig 16
18 112 Analog section TRIG line test ADTRG Sig 32
19 151 AD operation ZERO X10 ADx10 Zero 64
20 152 AD operation ZERO X1 ADx1 Zero 128
21 201 VSVM 300mV ZERO VSVM 0.3V Z
c
1
22 202 VSVM 300mV +FS VSVM 0.3V +F 2
23 203 VSVM 300mV -FS VSVM 0.3V -F 4
24 204 VSVM 3V ZERO VSVM 3V Zero 8
25 205 VSVM 3V +FS VSVM 3V +FS 16
26 206 VSVM 3V -FS VSVM 3V -FS 32
27 207 VSVM 30V ZERO VSVM 30V Z 64 -
28 208 VSVM 30V +FS VSVM 30V +FS 128 -
29 209 VSVM 30V -FS VSVM 30V -FS 256 -
30 207 VSVM 6V ZERO VSVM 6V Zero 64 -
31 208 VSVM 6V +FS VSVM 6V +FS 128 -
32 209 VSVM 6V -FS VSVM 6V -FS 256 -
33 211 High Limit 300mV +FS HL 0.3V +FS 512
34 212 High Limit 300mV -FS HL 0.3V -FS 1024
35 213 High Limit 3V +FS HL 3V +FS 2048
36 214 High Limit 3V -FS HL 3V -FS 4096
37 215 High Limit 30V +FS HL 30V +FS 8192 -
38 216 High Limit 30V -FS HL 30V -FS 16384 -
39 215 High Limit 6V +FS HL 6V +FS 8192 -
40 216 High Limit 6V -FS HL 6V -FS 16384 -
To Next Page
