6241A/6242 DC Voltage Current Source/Monitor Operation Manual
9. SPECIFICATIONS
9-1
9. SPECIFICATIONS
All accuracy specifications are guaranteed for one year at a temperature of 23 ± 5°C and a relative humidity
not exceeding 85%.
9.1 Source and Measurement
9.1.1 6241A Source and Measurement
However the measurement resolution with Integration time 100 μs, 500 μs and S/H (Sample Hold) is as
follows.
Range Source range
Setting
Resolution
Measurement
range
Measurement
Resolution
Voltage-source/
measurement
range
300 mV 0 to ± 320.00 mV 10 μV0 to ± 320.999 mV 1 μV
3 V 0 to ± 3.2000 V 100 μV0 to ± 3.20999 V 10 μV
30 V 0 to ± 32.000 V 1 mV 0 to ± 32.0999 V 100 μV
Current-source/
measurement
range
30 μA0 to ± 32.000 μA1 nA0 to ± 32.0999 μA 100 pA
300 μA0 to ± 320.00 μA 10 nA 0 to ± 320.999 μA1 nA
3 mA 0 to ± 3.2000 mA 100 nA 0 to ± 3.20999 mA 10 nA
30 mA 0 to ± 32.000 mA 1 μA0 to ± 32.0999 mA 100 nA
300 mA 0 to ± 320.00 mA 10 μA0 to ± 320.999 mA 1 μA
500 mA 0 to ± 500.00 mA 20 μA0 to ± 500.999 mA 1 μA
Resistance
measurement
Determined by
voltage range
and current
range calcula-
tions
- - 0 to 1.6 GΩ Minimum
2 μΩ
Integration time 100 μs 500 μsS/H (100 μs)
Measurement resolution
(digits)
10 2 10
