6241A/6242 DC Voltage Current Source/Monitor Operation Manual
9.1.1 6241A Source and Measurement
9-2
Voltage- and Current-limiter (compliance) range:
Overall accuracy: Includes calibration accuracy, 1-day stability, the temperature coefficient, and
linearity.
1-day stability: At Power and Load constant
Temperature coefficient: Temperature of 0 to 50°C
Maximum setting range Setting resolution
*1
Voltage-limiter 0 V to 320 mV 100 μV
320.1 mV to 3.2 V 1 mV
3.201 V to 32 V 10 mV
Current-limiter 100 nA to 32 μA 10 nA
32.01 μA to 320 μA 100 nA
320.1 μA to 3.2 mA 1 μA
3.201 mA to 32 mA 10 μA
32.01 mA to 320 mA 100 μA
320.1 mA to 500 mA 100 μA
*1: Where, (Hi limiter value - Lo limiter value) ≥ 60 digits
Range
Overall accuracy 1-day stability Temperature coefficient
± (% of setting + V) ± (ppm of setting + V)/°C
Voltage-source 300 mV 0.02 + 150 μV 0.01 + 70 μV15 + 15 μV
3 V 0.02 + 350 μV 0.01 + 200 μV15 + 30 μV
30 V 0.02 + 3 mV
*2
0.01 + 2 mV 15 + 300 μV
Voltage-limiter 300 mV 0.10 + 500 μV
*3
0.05 + 200 μV 100 + 50 μV
3 V 0.05 + 3 mV
*3
0.01 + 1 mV 15 + 100 μV
30 V 0.05 + 30 mV
*3
0.01 + 10 mV 15 + 1 mV
*2: 30 V range adds 200 μV per the remote sense voltage 0.1 V.
*3: Voltage limiter additional error: If Hi limiter is set to a negative value and Lo limiter is set to a positive
value, add an error of ±0.1 % of setting.
