6241A/6242 DC Voltage Current Source/Monitor Operation Manual
9.1.2 6242 Source and Measurement
9-8
9.1.2 6242 Source and Measurement
However the measurement resolution with Integration time 100 µs, 500 µs and S/H (sample hold) are as
follows.
Range Source range
Setting
resolution
Measurement
range
Measurement
resolution
Voltage-source/
measurement
range
300 mV 0 to ± 320.00 mV 10 μV0 to ± 320.999 mV 1 μV
3 V 0 to ± 3.2000 V 100 μV0 to ± 3.20999 V 10 μV
6 V 0 to ± 6.000 V 1 mV 0 to ± 6.0999 V 100 μV
Current-source/
measurement
range
30 μA0 to ± 32.000 μA1 nA0 to ± 32.0999 μA 100 pA
300 μA0 to ± 320.00 μA 10 nA 0 to ± 320.999 μA1 nA
3 mA 0 to ± 3.2000 mA 100 nA 0 to ± 3.20999 mA 10 nA
30 mA 0 to ± 32,000 mA 1 μA0 to ± 32.0999 mA 100 nA
300 mA 0 to ± 320.00 mA 10 μA0 to ± 320.999 mA 1 μA
3 A 0 to ± 3.0000 A 100 μA0 to ± 3.00999 A 10 μA
5 A 0 to ± 5.0000 A 200 μA0 to ± 5.00999 A 10 μA
Resistance
measurement
Determined by
voltage range
and current
range calcula-
tions
- - 0 to 304 MΩ Minimum
0.2 μΩ
Integration time 100 μs 500 μsS/H (100 μs)
Measurement resolution
(digits)
10 2 10
