6241A/6242 DC Voltage Current Source/Monitor Operation Manual
8.1.5 Calibrating Operation
8-8
Figure 8-5 6241A Calibration Procedure (4)
Current-source and
Limiter calibration
[Setting calibration mode]
IL-Hi IL-Lo modeIS mode
[Setting range]
Execute the DMM data input.
XD DMM data
Execute the calibration result check.
Acquire
DMM data.
Input DMM data.
ex. “XD-2.0e-6”
*Input data outside the set range results in a parameter error.
XD DMM data
Acquire
DMM data.
Input DMM data.
ex. “XD3003.0e-6”
*Input data outside the set range results in a parameter error.
Acquire
DMM data.
Acquire
DMM data.
Store and display
calibration result data.
Store and display
calibration result data.
Within
tolerance?
