ADCMT 6241A User Manual

6241A/6242 DC Voltage Current Source/Monitor Operation Manual
8.1.5 Calibrating Operation
8-7
Figure 8-4 6241A Calibration Procedure (3)
Voltage-measurement
calibration
VM mode
[Setting range]
Execute the DMM data input.
Acquire
DMM data.
Readout the
measurement data.
XD DMM data
Input DMM data.
ex. “XD-2.0e-6”
Acquire
DMM data.
Store and display
calibration result data.
XD DMM data
Input DMM data.
ex. “XD3003.0e-3”
*Input data outside the set range results in a
parameter error.
Readout the
measurement data.
Store and display
calibration result data.
*Input data outside the set range results in a
parameter error.
Within
tolerance?
