6241A/6242 DC Voltage Current Source/Monitor Operation Manual
6.3 GPIB
6-5
6.3 GPIB
6.3.1 Overview
GPIB (General Purpose Interface Bus) allows external control of the 6241A/6242 measurement function
settings, measurement parameter settings, and reading measurement data, making it simple to configure
an automated measurement system.
As GPIB signals from the 6241A/6242 are electrically isolated inside the unit from the measurement signal
system, the connection of external devices does not affect the measured values. The remote commands are
the same as with USB.
• General Specification
Standard: IEEE-488.2
Code: ASCII code
Logic level: Logical 0 (High) +2.4 V min.
Logical 1 (Low) +0.4 V max.
Table 6-1 Interface Function
Code Function
SH1 Source Handshake function
AH1 Acceptor Handshake function
T5 Basic Talker function, Talker Clear function specified by the lis-
tener, Talk-Only Mode function, Serial Poll function
L4 Basic Listener function and Listener Clear function specified by
the talker
SR1 Service Request function
RL1 Remote/Local switching function
PP0 Without the Parallel Poll function
DC1 Device Clear function (The SDC and DCL commands can be
used.)
DT1 Device Trigger function (GET command can be used.)
C0 Without the Controller function
E2 3-state bus driver used
