6241A/6242 DC Voltage Current Source/Monitor Operation Manual
7. PERFORMANCE TEST
7-1
7. PERFORMANCE TEST
This chapter describes the methods for checking whether the 6241A/6242 can operate in the specified accu-
racy.
7.1 6241A Tests
7.1.1 Measuring Instruments Required for Performance Tests
The test measuring instruments required for the performance tests are the same as those shown in Section
8.1.1, “Cables and Measuring Instruments Required for Calibration.”
7.1.2 Connection
The connections required for the performance test are the same as shown in Figure 8-1, “Connections for
6241A Calibration.”
7.1.3 Test Methods
Execute the performance test under the following conditions in a location free of dust, vibration, noise or
other adverse conditions:
Temperature: 23 ± 5ºC
Relative humidity: 70% or lower
Warm-up: 60 minutes or longer
Self-test, display, key, and buzzer tests
1. Press MENU key to select SYSTEM in the parameter group and refer to Section
5.2.15, “Self Test” to execute.
NOTE: If Error is displayed during the test, refer to Section 5.2.15, “Self Test” to
verify the content of the error.
To Next Page
