6241A/6242 DC Voltage Current Source/Monitor Operation Manual
2.2.3 Menu Operation
2-28
2.2.3.2 Menu Structure and Parameter Setting
The parameter type indicates the setting method at the Input/Run level.
Numeric data divided by a slash (/) represent the 6241A setting range/6242 setting range.
1) PLS Base Pulse source base value Numeric
VS +000.00 mV to ±32.000 V/+000.00 mV to ±06.000 V
IS +00.000 μA to ±500.00 mA/+00.000 μA to ±5.0000 A
2) Suspend V Output voltage in Suspend
+000.00 mV to ±32.000 V/+000.00 mV to ±06.000 V
Numeric
3) Suspend Z Output impedance in Suspend
HiZ/LoZ
Select
4) LMT Input Setting the Limiter
±Balance/Separate
Select
5) Response Output response
Fast/Slow
Select
MENU
A) SOURCE
(a)
Category level
Select level Input/Run level
B) SWEEP
Parameter
types
1) SweepType Sweep generation mode
Linear/Fixed/Random/Linear 2
Select
2) SWP Range Source range when sweeping
Auto/Fix
Select
3) Reverse Sweep reverse mode
Off/On
Select
4) Repeat Cnt Number of times sweep is repeated
0 to 1000
Numeric
5) Rtrn Bias Bias value output when sweep is completed
On/Off
Select
To Next Page
