6241A/6242 DC Voltage Current Source/Monitor Operation Manual
2.2.3 Menu Operation
2-29
1) Start Value
Linear Sweep Start value In the Linear mode
Numeric
VS +000.00 mV to ±32.000 V/+000.00 mV to ±06.000 V
IS +00.000 μA to ±500.00 mA/+00.000 μA to ±5.0000 A
2) Stop Value
Linear Sweep Stop value In the Linear mode
Numeric
VS +000.00 mV to ±32.000 V/+000.00 mV to ±06.000 V
IS +00.000 μA to ±500.00 mA/+00.000 μA to ±5.0000 A
3) Step Value
Linear Sweep Step value In the Linear mode
Numeric
VS 000.01 mV to 32.000 V/+000.01 mV to ±06.000 V
IS 00.001 μA to 500.00 mA/00.001 μA to 5.0000 A
1) Level Value
Fixed Sweep Level Value In the Fixed mode
Numeric
VS +000.00 mV to ±32.000 V/+000.00 mV to ±06.000 V
IS +00.000 μA to ±500.00 mA/+00.000 μA to ±5.0000 A
2) Sample Cnt
Fixed Sweep Sample Count In the Fixed mode
Numeric
1 to 8000
1) Sweep Adr
Random sweep start address/stop address In the Random mode
Numeric
0 to 7999
* Use [SEL] key to switch between Start/Stop.
1) First Value
Two-slope Linear Sweep First value In the Linear 2 mode
Numeric
VS +000.00 mV to ±32.000 V/+000.00 mV to ±06.000 V
IS +00.000 μA to ±500.00 mA/+00.000 μA to ±5.0000 A
2) Middle Value
Two-slope Linear Sweep Middle value In the Linear 2 mode
Numeric
VS +000.00 mV to ±32.000 V/+000.00 mV to ±06.000 V
IS +00.000 μA to ±500.00 mA/+00.000 μA to ±5.0000 A
3) Last Value
Two-slope Linear Sweep Last value In the Linear 2 mode
Numeric
VS +000.00 mV to ±32.000 V/+000.00 mV to ±06.000 V
IS +00.000 μA to ±500.00 mA/+00.000 μA to ±5.0000 A
4) Step1 Val
Two-slope Linear Sweep Step1 value In the Linear 2 mode
Numeric
VS 000.01 mV to 32.000 V/+000.01 mV to ±06.000 V
IS 00.001 μA to 500.00 mA/00.001 μA to 5.0000 A
5) Step2 Val
Two-slope Linear Sweep Step2 value In the Linear 2 mode
Numeric
VS 000.01 mV to 32.000 V/000.01 mV to 06.000 V
IS 00.001 μA to 500.00 mA/00.001 μA to 5.0000 A
6) Bias Value
Sweep bias value
Numeric
VS +000.00 mV to ±32.000 V/+000.00 mV to ±06.000 V
IS +00.000 μA to ±500.00 mA/+00.000 μA to ±5.0000 A
7) PSW Base
Pulse sweep base value
Numeric
VS +000.00 mV to ±32.000 V/+000.000 mV to ±06.000 V
IS +00.000 μA to ±500.00 mA/+00.000 μA to ±5.0000 A
C) SWEEP VAL
Category level
Select level Input/Run level
Parameter
types
(a)
(b)
To Next Page
