6241A/6242 DC Voltage Current Source/Monitor Operation Manual
2.2.3 Menu Operation
2-30
1) Hold Time Hold time
1 ms to 60 s
Numeric
2) Src Delay Source delay time
30 μs to 59.998 s
Numeric
3) Meas Delay Measurement delay time
50 μs to 59.998 s
Numeric
4) Pls Width Pulse width
50 μs to 59.998 s
Numeric
5) Period Period (pulse cycle)
500 μs to 60 s
Numeric
6) A.Rng Delay Auto range delay time
0 ms to 500 ms
Numeric
D) TIME
(c)
Category level
Select level Input/Run level
E) MEASURE
Parameter
types
1) Auto Zero Measurement auto zero
On/Off
Select
2) Integ Time Integration time
100 µs/500 µs/1 ms/5 ms/10 ms/1 PLC /100 ms/200 ms/S/H
* S/H is available only in the Pulse or Pulse Sweep source
modes.
Select
3) Measure SW Measurement ON or OFF
On/Off
Select
4) Disp Digit Measurement digits
5 digits/4 digits /3 digits
Select
5) Disp Unit Switching the unit display
Prefix/Exponent
Select
6) Mfunc Link Measurement function link mode
On/Off
Select
(b)
F) MEMORY
1) Store Mode Measurement data memory
Off/Normal/Burst
Select
2) Mem Recall Measurement data memory recall
Recall data number setting
Numeric
3) Mem Clear Measurement data memory clear
Press [ENTER] key to run.
Run
