ADCMT 6241A User Manual

6241A/6242 DC Voltage Current Source/Monitor Operation Manual
A-7
A.3 Execution Time
A.3.1 GPIB/USB Remote Execution Time (Typical Value)
Computer: FMV6667CL6c manufactured by FUJITSU, Windows98SE
GPIB hardware: PCI-GPIB (NATIONAL INSTRUMENTS)
Language: Visual Basic 6
Item Program code Conditions
GPIB
Unit [ms]
USB
Unit [ms]
Operate,
Suspend, or
Standby
Operate OPR
(At Standby) Source mode: DC, pulse
IT: 1 PLC (20 ms)
Source function: VS/IS
Others: Default values
127/93 139/104
(In Suspend HiZ)
50/17 63/28
(In Suspend LoZ)
12/17 24/28
OPR
(At Standby) Source mode: Sweep
Number of steps: 100
IT: 1 PLC (20 ms)
Others: Default values
170 181
(In Suspend HiZ)
51 63
(In Suspend LoZ)
12 25
Suspend SUS
(OPR → SUS LoZ) Source mode: DC, pulse
IT: 1 PLC (20 ms)
Source function: VS/IS
Others: Default values
11/17 24/29
(OPR → SUS HiZ)
53/18 65/30
(SBY → SUS LoZ)
126/88 137/98
(SBY → SUS HiZ)
87/87 98/98
Standby SBY
(In Operate) Source mode: DC, pulse
IT: 1 PLC (20 ms)
Source function: VS/IS
Others: Default values
94/61 106/71
(In Suspend HiZ)
51/51 64/64
(In Suspend LoZ)
93/52 106/64
Source function VF
(In IS operational status) Source mode: DC, pulse
20 to 62 33 to 72
(In Suspend) Operate and HOLD status
10 22
IF
(In VS operational status)
55 to 61 66 to 73
(In Suspend)
10 22
Change the source range
V3 to V5 (Setting VF)
14 to 16 26 to 28
I-1 to I4 / I-1 to I5 (Setting IF)
28 to 51 40 to 64
