6241A/6242 DC Voltage Current Source/Monitor Operation Manual
A-8
Voltage-source*
Source value
Pulse value
Base value
Bias value
SOV<data>
BS<data>
SB<data>
Operate
and
HOLD
status
Range not
changed
9 to 12 22 to 25
Range changed
15 to 28 26 to 42
Current-source*
Source value
Pulse value
Base value
Bias value
SOI<data>
BS<data>
SB<data>
Range not
changed
21 to 29 35 to 43
Range changed
43 to 66 57 to 79
Voltage-limiter value*
LMV<data>
Range not
changed
9 to 11 22 to 24
Range changed
14 to 27 25 to 42
Current-limiter value*
LMI>data>
Range not
changed
22 to 25 36 to 41
Range changed
42 to 66 55 to 79
Measurement function F0 to F3
Source mode: DC, pulse
Operate and HOLD status
10 23
Integration time IT0 12 25
IT1 13 26
IT2 14 27
IT3 22 35
IT4 33 45
IT5 52 65
IT6 212 225
IT7 412 425
Time
parameter
Th, Td, Tp, Tw SP<data>,<data>,<data>,<data> 15 to 18 31 to 35
Tds SD<data> 9 to 20 23 to 36
Sweep
type*
Linear SN<data>
Standby status
12 to 36 26 to 52
Fixed SF<data> 10 to 11 24 to 26
Random SC<data> 9 to 10 23 to 25
Two-slope SM<data> 15 to 67 31 to 86
Source mode MD0 to MD3 9 23
Set random da
ta *
N<adrs>,
<data>,
P
12 to 28
30 to 47
* The command with <data> is different in processing time according to the data length.
Item Program code Conditions
GPIB
Unit [ms]
USB
Unit [ms]
To Next Page
