6241A/6242 DC Voltage Current Source/Monitor Operation Manual
A-9
1. Measurement execution time
Conditions: Source range; Fixed
Measurement range; fixed, Trigger mode; external trigger, Number of measurement
digits; 5½ digits
Integration time; 100 μs, Measurement delay; 0.3 ms, Source delay; 30 μs
Period; 2 ms, Pulse width; 1 ms
Header; OFF, Block delimiter; EOI (DL2)
• The time from trigger input (*TRG) to measurement and to completion of data output to GPIB/
USB
• The time from Receiving source command + Measurement by Trigger input (*TRG) and to
completing data output to GPIB/USB
In DC or Pulse source mode
• The time from measurement due to receiving a spot command (measurement trigger after set-
ting the source value for currently set Source function) to completion of data output to GPIB/
USB.
In DC or Pulse source mode
Conditions for source value
GPIB
Execution
time
USB
Execution
time
When DC or Pulse source is generated 9 ms 18 ms
When Sweep start value is generated 12 ms 21 ms
When Sweep step value is generated 10 ms 19 ms
Source Command
GPIB
Execution
time
USB
Execution
time
Voltage-source SOV<data> (<data>: 1 character) 13 ms 23 ms
Current-source SOI<data> (No unit, < data>: 3 characters) 14 ms 25 ms
Source Command
GPIB
Execution
time
USB
Execution
time
Voltage-source G<data> (<data>: 1 character) 11 ms 19 ms
Current-source G<data> (No unit, < data>: 3 characters) 12 ms 21 ms
