6241A/6242 DC Voltage Current Source/Monitor Operation Manual
A-10
2. Data read time
3. Sweep start to Data read time
Indicates a time from executing 100 step sweep to completing the data output from memory to GPIB
with RN1 command.
Conditions: Source range; Fixed
Measurement range; Fixed, Trigger mode; Internal trigger, Number of measurement
digits; 5½ digits, Integration time; 100 µs
Measurement delay; 0.1 ms, Hold time;1 ms, Source delay; 30 µs,
Pulse width; 1 ms
Header; OFF, Block delimiter; EOI (DL2)
Item
Number of
data
GPIB
Execution
time
USB
Execution
time
Source-value data-reading by Query 1 6 ms 18 ms
Read measurement buffer memory after
RN1 command
Condition: number of measurement digits;
5½ digits, Header; OFF, Block delimiter;
EOI (DL2)
1 7 ms 20 ms
100 403 ms 1.33 s
Memory mode Period
GPIB Execution
time
Normal-ON 10 ms 1.4 s
Burst-ON 2 ms 0.6 s
