6241A/6242 DC Voltage Current Source/Monitor Operation Manual
2.2.3 Menu Operation
2-26
Figure 2-14 Menu Operation Overview
*1 Enter a parameter to return to the normal screen.
*2 Enter a parameter to return from the Input/Run level to the Category level.
*3 Press [EXIT] to discard the input data and revert to the directly set value.
*4 Enabled for two parameter settings.
*5 Enabled when “Push ENTER” is displayed.
HOME screen
Level 1
Category level
Select level
Input/Run level
Level 2
Level 3
Cursor flashes
on numeric
parameter
Select parameter
blinks
Direct input
Numeric value
Unit
To Next Page
