6241A/6242 DC Voltage Current Source/Monitor Operation Manual
2.2.1 Setting Source Value
2-18
2.2.1.3 Setting Source Value Using Cursor Keys/Rotary Knob (when FIT Indicator is
ON)
When the FIT indicator turns on, the range is adjusted so that the source value is generated in the optimum
range.
The following figures describe the setting procedure.
1. Press . The cursor moves to the left.
2. Press or rotate one click clockwise to change the 3 V setting to 4 V. The
source range is automatically set to 30 V/6 V.
Cursor (blinking)
Cursor (blinking)
Cursor (blinking)
