6241A/6242 DC Voltage Current Source/Monitor Operation Manual
5.2.9 Calculation Functions
5-50
5.2.9.2 Scaling Calculation
1. Calculation expression
Scaling calculation is defined using the following formula:
2. Operation
• When Scaling calculation is ON, MATH indicator illuminates.
• The set ranges of Constant A, Constant B, and Constant C are 0 to ±999.999E+24 (however,
Constant A ≠ 0).
• If the calculation results exceed ±999.999E + 24, it is scaling-over and the error message ±SCL
Over is displayed.
• This function is turned OFF by executing the *RST command.
• Changing the measurement function does not turn OFF this function.
Scaling calculation =
Constant A
X-Constant B
Constant C
×
X: Measurement value
