6241A/6242 DC Voltage Current Source/Monitor Operation Manual
A-4
Self-test 211 HL 0.3V +FS High Limit 300 mV +FS test error
212 HL 0.3V -FS High Limit 300 mV -FS test error
213 HL 3V +FS High Limit 3 V +FS test error
214 HL 3V -FS High Limit 3 V -FS test error
215
HL 30V +FS High Limit 30 V +FS test error -
HL 6V +FS High Limit 6 V +FS test error -
216
HL 30V -FS High Limit 30 V -FS test error -
HL 6V -FS High Limit 6 V -FS test error -
221 LL 0.3V +FS Low Limit 300 mV +FS test error
222 LL 0.3V -FS Low Limit 300 mV -FS test error
223 LL 3V +FS Low Limit 3 V +FS test error
224 LL 3V -FS Low Limit 3 V -FS test error
225
LL 30V +FS Low Limit 30 V +FS test error -
LL 6V +FS Low Limit 6 V +FS test error -
226
LL 30V -FS Low Limit 30 V -FS test error -
LL 6V -FS Low Limit 6 V -FS test error -
231 IM 30µA Zero IM 30 µA Zero test error
232 IM 300µA Z IM 300 µA Zero test error
233 IM 3mA Zero IM 3 mA Zero test error
234 IM 30mA Zero IM 30 mA Zero test error
235 IM 300mA Z IM 300 mA Zero test error
236
IM 500mA Z IM 500 mA Zero test error -
IM 3A Zero IM 3A Zero test error -
237 IM 5A Zero IM 5A Zero test error -
241 IS 30µA +FS ISIM 30 µA +FS test error
242 IS 30µA -FS ISIM 30 µA -FS test error
243 IS 300µA +FS ISIM 300 µA +FS test error
244 IS 300µA -FS ISIM 300 µA -FS test error
245 IS 3mA +FS ISIM 3 mA +FS test error
246 IS 3mA -FS ISIM 3 mA -FS test error
247 IS 30mA +FS ISIM 30 mA +FS test error
248 IS 30mA -FS ISIM 30 mA -FS test error
249 IS 300mA +FS ISIM 300 mA +FS test error
250 IS 300mA -FS ISIM 300 mA -FS test error
Table A-2 Error Message List (2/4)
Classification
Display
error code
Message Explanation 6241A 6242
