6241A/6242 DC Voltage Current Source/Monitor Operation Manual
A-5
Self-test
251
IS 500mA +FS ISIM 500 mA +FS test error -
IS 3A +FS ISIM 3A +FS test error -
252
IS 500mA -FS ISIM 500 mA -FS test error -
IS 3A -FS ISIM 3A -FS test error -
253 IS 5A +FS ISIM 5A +FS test error -
254 IS 5A -FS ISIM 5A -FS test error -
301 OVL Check OVL-detection-check error
311 S/H Check Sample hold test error
130 No resp SCI SCI communication error
501 CAL dt Lost CAL data lost
502 Save dt Lost Parameters saved with STP command lost
503 Para dt Lost Saved parameters lost
571 Rly Limited Operate relay operated more than one million time.
Hard error 401 Fan Stopped Fan stopped
402 Over Heat Overheat
403 Source Unit Source circuit error
404 Over Load Overload
Source and Mea-
surement
error
- ±OverRange Measurement range over
- HiLimit RM/LoLimit RM Resistance measurement under the limit status
- VSource=0 Measurement of resistance with Source value = 0
- Count Few IS is below 20 counts, or IM is below 200 counts
- ±SCL Over Scaling over
- ±TotalOver Total value over
Operation 801 Over Step 8000 < Number of Sweep steps
822 Tp < Tds Timer condition error (Not Tp > Tds+300 µs)
823 Tp < Td Timer condition error (Not Tp > Td+300 µs)
824 Tp < Tds+Tw Timer condition error (Not Tp > Tds+Tw+300 µs)
825 Td < Tds Timer condition error (Not Td > Tds)
828 600ms < Tp S/H Timer condition error (Not Tp≤600 ms)
831 Interlock Disabled status by Interlock
855 CAL data Calibration data error
Table A-2 Error Message List (3/4)
