6241A/6242 DC Voltage Current Source/Monitor Operation Manual
9.3 Set Time
9-18
Period (pulse cycle):
Pulse width:
Measurement delay time:
Hold time:
Auto range delay time
Set range
Setting
resolution
*7
Accuracy
0.500 ms to 60.000 ms 1 μs
60.01 ms to 600.00 ms 10 μs ±(0.1% + 10 μs)
600.1 ms to 6000.0 ms 100 μs
6001 ms to 60000 ms 1 ms
Set range
Setting
resolution
*7
Accuracy
0.050 ms to 60.000 ms 1 μs
60.01 ms to 600.00 ms 10 μs ±(0.1% + 10 μs)
600.1 ms to 6000.0 ms 100 μs
6001 ms to 59998 ms 1 ms
Set range
Setting
resolution
*7
Accuracy
0.050 ms to 60.000 ms 1 μs
60.01 ms to 600.00 ms 10 μs ±(0.1% + 10 μs)
600.1 ms to 6000.0 ms 100 μs
6001 ms to 59998 ms 1 ms
*7: The setting resolution is determined by the period time
resolution.
Set range Resolution Accuracy
1 ms to 60000 ms 1 ms ±(2% + 3 ms)
Set range Resolution Accuracy
0 ms to 500 ms 1 ms ±(2% + 3 ms)
