CALL:MS:ANALog
CALL:MS:ANALog
“Diagram Conventions” on page 248
CALL:MS:ANALog:TXLevel[:IMMediate]
Function Sets/queries the mobile station transmit level while on an analog voice channel.
This command is used in active cell operating mode to immediately change the mobile level while
on an AVC.
Setting Range: 0 to 7
MS TX Level 0: expected power, 36 dBm*
MS TX Level 1: expected power, 32 dBm
MS TX Level 2: expected power, 28 dBm
MS TX Level 3: expected power, 24 dBm
MS TX Level 4:expected power, 20 dBm
MS TX Level 5: expected power, 16 dBm
MS TX Level 6: expected power, 12 dBm
MS TX Level 7: expected power, 8 dBm
*all values for MS TX level assume 0 dB antenna gain
Query Range: 0 to 7
*RST Setting 2
Programming Example
OUTPUT 714;”CALL:MS:ANALOG:TXLEVEL 5”
!Sets mobile station AVC transmit power level to 5
(expected power 16 dBm).
<sp><num value>
CALL :MS
:ANALog
:TXLevel
[:IMMediate]
