CALL:[:CELL]:RLGain
CALL:[:CELL]:RLGain
“Diagram Conventions” on page 248
CALL[:CELL]:RLGain[:TTPilot]
Function Sets/queries reverse link, traffic-to-pilot level (RLGAIN_TRAFFIC_PILOT) gain.
RLGAIN_TRAFFIC_PILOT is sent in an overhead message to the mobile station and is used by
the mobile station to adjust the reverse channel traffic channel level, relative to the reverse
channel pilot. This parameter applies only when the current radio configuration is greater than
2.
Each integer translates into a 1/8 dB step.
Setting Range: -32 to +31
Resolution: integer
Query Range: -32 to+31
Resolution: integer
*RST Setting 0
Programming Example
OUTPUT 714;"CALL:CELL:RLGAIN:TTPILOT 8"
<sp><num value>
CALL
:RLGain
[:TTPilot]
? (returns num value)
[:CELL]
