cdma2000 Measurement Procedures
Measuring TDSO (Test Data Service Option) Frame Error Rate (FER)
1. Press the CALL SETUP key.
2. If a call is currently connected, press the End Call key (
F3).
3. Press the Radio Config key (
F11).
4. Select one of the following radio configurations:
• (Fwd3, Rvs3)
• (Fwd4, Rvs3)
5. Press the FCH Service Option Setup key (
F12).
6. Select the Service Option for the currently selected radio configuration, then select SO32 (+F-SCH).
7. Press the
Measurement selection key.
8. Select the TDSO Frame Error Rate measurement.
9. Press the TDSO FER Setup (
F1) key.
10.Set up the measurement parameters as needed for your measurement situation.
11.Press the
CALL SETUP key.
12.Press the Originate Call key (
F3).
13.Press the
MEASUREMENT key. Wait for the call to connect, then wait approximately 10 seconds for the
measurement to begin. A typical display is shown below.
14.Press the TDSO FER Setup (
F1) key.
15.Set up the measurement parameters as needed for your measurement situation.
