CALL:D2KTest
CALL:D2KTest
“Diagram Conventions” on page 248
CALL:D2KTest:EIRPower[:MAXimum]
Function Sets/queries the test mode maximum EIRP (Effective Isotropic Radio Power).
The test set will adjust its receiver power range expecting a normal open loop power control
response from the mobile station. However, when cell power is lowered the expected power to the
test set’s receiver will not increase beyond max EIRP.
If an amplitude offset is turned on (see “SYSTem:CORRection:[:SGAin]” ), the test set will
automatically adjust the max EIRP value to correct for path loss.
Setting Range: -30 to +10 dBW
Resolution: 1 dBW
Query Range: -30 to +10 dBW
Resolution: 1 dBW
*RST Setting -7 dBW
Programming Example
OUTPUT 714;"CALL:D2KTEST:EIRPOWER:MAXIMUM -2" !Sets the mobile station max EIRP to -2 dBW.
:INDicator
<sp><string>:ESNumber
? (returns string)
CALL
<sp><num value>[DBW|DBM]
[:MAXimum]
?(returns dBm num value)
:EIRPower
:HEX
:D2KTest
:QPCHannel
<sp>[ALL0|ALL1]
?(returns ALL0|ALL1)
[:PAGing]
