SYSTem:CORRection
SYSTem:CORRection:[:SGAin]
Function Sets/queries up to 20 comma-separated amplitude offset values in dB. This command sets the
state to On.
See “Measurement Related Configuration” on page 81.
The units, dB, are optional. If no units are specified then units default to dB.
Sending a null list (no values) sets the state of all offsets to Off.
Setting Range: 0 to 20 values between
−100 to +100
Resolution: 0.01
Query Range: 1 to 20 values between
−100 to +100, and NAN (9.91E+37)
Resolution: 0.01
Factory
Setting
Offsets 1 through 20, are set to 0.00 dB, state is set to Off
Programming Example
OUTPUT 714;"SYSTEM:CORRECTION:SGAIN -2.55,-3.12,-3.68,-4.23,-4.74,-5.3"
!A complex command that sets up to 20 comma separated offsets
!and sets the state to On for the frequencies, offsets and
!RF IN/OUT Amplitude Offset State
OUTPUT 714;"SYSTEM:CORRECTION:SGAIN"
!Sets the state for all frequencies and offsets to Off
