Configuring the F-QPCH (Forward Quick Paging Channel)
Configuring the F-QPCH (Forward Quick Paging Channel)
The quick paging channel parameters are configured using the following call processing subsystem functions
and commands.
Settable F-QPCH Parameters
• QPCH Level (relative to pilot channel power).
• QPCH Level (relative to cell power).
• QPCH State (on or off).
• QPCH Indicator bits (applied only when the test set’s operating mode is IS-2000 test mode. (See
“CALL:D2KTest:QPCHannel:INDicator[:PAGing]” .)
Fixed F-QPCH Parameters
• QPCH_RATE is fixed at 9600 bps
• QPCH_CCI_SUPPORTED is fixed at 0.
• NUM_QPCH is fixed at 1.
• The F-QPCH Walsh code is fixed at code channel number 80.
GPIB Examples:
Setting F-QPCH Level (relative to pilot channel level)
OUTPUT 714;"CALL:QPCH:RTP -3 DB"
would set the F-QPCH state on and set the level, relative to the forward channel pilot, to −3 dB. See “CALL:
QPCHannel[:SLEVel]:RTPilot[:SELected]” .
Querying F-QPCH Level (relative to cell power level)
OUTPUT 714;"CALL:QPCH:LEVel?"
would query the last F-QPCH relative to cell power level setting. See “CALL:
QPCHannel:LEVel[:RTCell][:SELected]?” .
