358
S:\Hp8960\E1962B CDMA 2000\Pi Release\Reference Guide\Chapters\cdma2000_hpib_call_qpchannel.fm
CALL:QPCHannel
CALL:QPCHannel[:SLEVel]:RTPilot[:SELected]
Function The setting form of this command performs two functions: (1) sets the forward quick paging
channel (QPCH) level relative to the pilot level, and (2) turns the QPCH state to ON.
The query form returns the QPCH level relative to the pilot level.
The optional [:SELected] keyword in this command specifies that the frequency band being
set/queried applies to the current system type.
The QPCH channel is slotted (pulsed).
When the state of the QPCH is on (see “CALL:QPCHannel:STATe” ), OCNS is calculated based
on the channel power when QPCH is present in the signal. When the QPCH state is off, the
output power is not fully calibrated.
Query Range: +2 to -5 dB
Resolution: integer
*RST Setting -3
Programming Example
OUTPUT 714;"CALL:QPCHANNEL:SLEVEL:RTPILOT:SELECTED?"
! Sets the QPCH level state to on and queries the QPCH level relative to the pilot power.
