Measurement Related Configuration
Figure 13. Amplitude Offset Interpolation
If testing is done outside the range of frequencies bounded by the lowest and highest frequency entries, the
test set simply uses the amplitude offset that is paired with the nearest frequency point.
IMPORTANT It is highly recommended that amplitude offsets are set up for each test frequency. This
eliminates inaccuracies due to the mismatch between the test set’s linear interpolation and the
actual frequency response of the RF path between the test set and mobile station.
Related Topics
“SYSTem:CORRection”
Amplitude Offset Interpolation
-5
-4
-3
-2
-1
0
800 890.2 890.6 891 914 1710 2000
Frequency (MHz)
Offset (dB)
Offset at 890.4 MHz
would equal -1.5 dB
