306

S:\Hp8960\E1962B CDMA 2000\Pi Release\Reference Guide\Chapters\cdma2000_hpib_call_ms_reported_b.fm

CALL:MS:REPorted:<BCL,BWT>

“Diagram Conventions” on page 248

CALL:MS:REPorted:BCLass?

CALL:MS:REPorted:BWType?

Function This query returns up to three concatenated mobile station reported frequency band classes

(frequency bands supported by the mobile station).

Each band that is included in the returned string is right-justified within an 8-character slot.

Each 8-character slot is followed by a comma and a space until the last band is sent. The last

band in the string will not have an appended comma and a space.

The return values for “CALL:MS:REPorted:OPERating:MODE?” and

“CALL:MS:REPorted:EIRPower[:MAXimum]?” will consist of an operating mode and a maximum

EIRP for each band returned by this command.

Each time a new mobile station registers with the test set, the test set will have the mobile

station report band classes, mobile station reported operating mode for each band class, and

mobile station reported max EIRP (if the operating mode is CDMA) for each band class. These

results are referred to as Status Request Information.

Query Range: US Cell, Jpn Cell, Kor PCS, US PCS, IMT-2000, null

*RST Setting Null

Programming Example

OUTPUT 714;"CALL:MS:REPORTED:BCLASS?"

!when sent to a mobile station supporting US cellular and US PCS bands, returns the string:

!“<sp>US<sp>Cell,<sp><sp><sp>US<sp>PCS".

!Note: string is 16 characters (8 per band) plus a comma and space separating the two bands.

Function Queries station class mark bandwidth support.

Query Range: BWT20|BWT25|UNKN

*RST Setting UNKN

Programming Example

OUTPUT 714;"CALL:MS:REPORTED:BWTYPE?"

CALL

(returns US Cell|Jpn Cell|Kor PCS|US PCS|

:BCLAss?

:BWType?

(returns BWT20|BWT25|UNKN)

:MS :REPorted

IMT-2000|null)
