CALL:TRIGger:TYPE
CALL:TRIGger:TYPE
“Diagram Conventions” on page 248
CALL:TRIGger[:OUTPut]:TYPE
Function Sets/queries the frame clock that is routed to the TRIG OUT rear panel connector. See “Rear
Panel Connectors” on page 688. Each choice consists of a CDMA frame clock period. For example,
MS20 is the 20 millisecond frame clock.
The triggers are based on the internally generated frame clock.
There is no on/off state setting for external triggers.
Setting Range: MS20|MS27|MS80|MS2000
Query Range: MS20|MS27|MS80|MS2000
*RST Setting MS2000 (2 seconds)
Programming Example
OUTPUT 714;"CALL:TRIGGER:OUTPUT:TYPE MS27"
!Sets the external trigger signal to 26.67 ms.
CALL
:TRIGger :TYPE
<sp>MS20|MS27|MS80|MS2000
? (returns MS20|MS27|MS80|MS2000)
[:OUTPut]
