CALL:MS:REPorted:CAPabiltiy:SCHannel:FORWard
CALL:MS:REPorted:CAPability:SCHannel:FORWard[:SUPPort]?
CALL:MS:REPorted:CAPability:SCHannel:FORWard:CONVolution[:SUPPort]?
CALL:MS:REPorted:CAPability:SCHannel:FORWard:CONVolution:DRATe1[:MAXimum]?
CALL:MS:REPorted:CAPability:SCHannel:FORWard:CONVolution:DRATe2[:MAXimum]?
Function This query only command returns the mobile station’s capability to support a forward
supplemental channel (SCH), as reported by the mobile station.
Query Range: YES|NO|UNKN
*RST Setting UNKN
Programming Example
OUTPUT 714;”CALL:MS:REPORTED:CAPABILITY:SCHANNEL:FORWARD:SUPPPORT?”
Function This query only command returns the mobile station’s capability to support convolutional coding
on the forward supplemental channel, as reported by the mobile station.
Query Range: YES|NO|UNKN
*RST Setting UNKN
Programming Example
OUTPUT 714;”CALL:MS:REPORTED:CAPABILITY:SCHANNEL:FORWARD:CONVOLUTION:SUPPORT?”
Function This query only command returns the mobile station’s maximum convolutional coder data rate on
the forward supplemental channel for rate set 1, as reported by the mobile station.
Query Range: BPS9600|BPS19200|BPS76800|BPS153600|BPS307200|UNKN
*RST Setting UNKN
Programming Example
OUTPUT 714;”CALL:MS:REPORTED:CAPABILITY:SCHANNEL:FORWARD:CONVOLUTION:DRATE1:MAXIMUM?”
Function This query only command returns the mobile station’s maximum convolutional coder data rate on
the forward supplemental channel for rate set 2, as reported by the mobile station.
Query Range: BPS14400|BPS28800|BPS57600|BPS230400|UNKN
*RST Setting UNKN
Programming Example
OUTPUT 714;”CALL:MS:REPORTED:CAPABILITY:SCHANNEL:FORWARD:CONVOLUTION:DRATE2:MAXIMUM?”
