412
S:\Hp8960\E1962B CDMA 2000\Pi Release\Reference Guide\Chapters\cdma2000_hpib_display.fm
DISPlay
DISPlay:BRIGhtness
DISPlay:MESSage:MASKable:STATe
DISPlay:MODE
Function Sets/queries the test set’s display brightness.
A display backlight dimming feature lowers the display brightness after approximately 10
minutes without any manual user interaction with the test set. See “Display Backlight Dimming”
on page 410.
Setting Range: MEDium | HIGH
Query Range: MED | HIGH
Factory
setting
HIGH (this parameter is not affected by any reset operation and can only be changed by direct
user access)
Programming Example
OUTPUT 714;"DISPLAY:BRIGHTNESS MEDIUM" !Sets display brightness to medium.
Function Blocks maskable messages from appearing on the test set display screen but not from the
Message Log. Maskable messages are reported to the Message Log in either state. See “Error
Messages” on page 719.
Setting Range: On | Off
Query Range: On | Off
Factory
setting
On
Programming Example
OUTPUT 714;"DISPLAY:MESSAGE:MASKABLE:STATE OFF"
!Prevents certain messages from appearing on the display.
Function Sets/queries the test set’s display mode.
See
“Display Mode (Track/Fast)” for a description of fast and track display modes.
Setting Range: FAST | TRACK
Query Range: FAST | TRAC
*RST setting TRACK
Programming Example
OUTPUT 714;"DISPLAY:MODE FAST" !Sets display mode to fast.
