569
S:\Hp8960\E1962B CDMA 2000\Pi Release\Reference Guide\Chapters\cdma2000_hpib_setup_wquality.fm
SETup:WQUality
SETup:WQUality:CDPower:IQINactive[:LIMit]
SETup:WQUality:CDPNoise:IQNoise[:LIMit]
SETup:WQUality:CONTinuous
Function Sets/queries the pass/fail limit for inactive channel power on the Code Domain Power
measurement .
Setting Range: -100 to 0 dB
Query Range: -100 to 0 dB
*RST Setting -26 dB
Programming Example
OUTPUT 714;"SETUP:WQUALITY:CDPOWER:IQINACTIVE:LIMIT -26 DB"
!Sets code domain power measurement’s pass/fail limit.
Function Sets/queries the pass/fail limit for noise energy measured by the Code Domain Power and Noise
measurement.
Setting Range: -100 to 0 dB
Query Range: -100 to 0 dB
*RST Setting -26 dB
Programming Example
OUTPUT 714;"SETUP:WQUALITY:CDPNOISE:IQNOISE:LIMIT?"
!Queries the code domain power plus noise measurement’s pass/fail limit.
Function Sets/queries the trigger arm state for the waveform quality measurement. The trigger arm state
determines whether the waveform quality measurement will be made once then stop (0|OFF
(single)), or automatically rearm upon completion of one measurement and repeat the process
(1|ON (continuous)).
Setting Range: 1|ON|0|OFF
Query Range: 1|0
*RST Setting 0 (off)
Programming Example
OUTPUT 714;"SETUP:WQUALITY:CONTINUOUS OFF"
!Sets measurement to single trigger mode.
